Chapter 4 Configuring the Preinstalled Microsoft Windows Server 2003 R2 Operating System 49
For additional information about which console option to select (Sun ILOM or local),
see
“Connecting to the Server Module ILOM” on page 13 .
Initial Setup of Preinstalled Windows
Server 2003 R2 OS
Follow these steps to boot the Windows preinstalled image, as well as to configure
the initial Windows operating system settings for language, licensing, date and time,
and network.
▼ To Perform the Initial Setup of the Preinstalled
Windows OS
1. Reset the server module, for example:
■
From the ILOM web interface , select Reset on the Remote Power Control tab.
■ From server module , press the Power button (momentary, 1 second) on the
front panel of the server module to turn off the server module, then press the
Power button (momentary, 1 second) to turn on the server module.
■ From ILOM CLI on the server module SP , type: reset /SYS
■ From ILOM CLI on the CMM , type reset /CH/BL#/SYS
where # is the slot number of the blade in the chassis
The BIOS POST screen appears then an EMS (Emergency Management Services)
Connection Detection dialog appears.
Tip – If your mouse or keyboard is not responding, wait until the device(s) are
properly detected.
2. In the EMS Connection Detection dialog box, click OK to continue using this
local connection.
The Welcome to Windows Setup dialog appears.
