Chapter 3 Configuring the Preinstalled Solaris 10 Operating System 43
8. Click the screen to activate the Managed Systems List.
9. Double-click the local machine (it is displayed by IP Address of the Primary
ENET connection).
A prompt appears.
10. At the prompt, log in as root, using the OS password that was assigned during
Solaris installation.
11. Click the SUN STK RAID Controller.
All attached hard disk drives on Enclosure 0 and 1 appear.
Tip – HDD0 (OS) should be Enclosure 0 Logical Volume 1.
12. To mirror the OS, right-click Logical Device 1 and choose Expand or Change
Logical Device.
13. Choose the appropriate RAID option (in this example, RAID 1 for Mirror).
14. Choose a disk to mirror the OS with, from the physical disk list.
Select the hard disk drive that best fits your needs.
15. After you select the HDD, click Next, and then view the configuration
summary.
16. Click Apply to start the mirroring process.
You can also click Schedule to perform the mirroring process at a later time.
17. Another confirmation screen appears. Confirm to start the mirroring process.
The OS begins to mirror. Mirroring may take several hours, depending on the
amount of data and the HDD size.
Solaris 10 Operating System User
Information
This section provides pointers to information about the Solaris 10 Operating System.
Solaris 10 User Documentation
You can access the various collections of the Solaris 10 OS user documentation at:
http://docs.sun.com/app/docs/prod/solaris.10
