Data Communications Setup
•••• 49
Configuring Your PC
The Advance DataNET Hub (DNH) has a built-in utility for configuring its
operation. The Windows
HyperTerminal program that resides on most
PCs can be used to access this utility. Other serial communication pack-
ages that support the following settings can also be used.
Baud rate:
57.6k baud
Data bits:
8
Parity: none
Stop bits:
1
Flow control:
none
This procedure uses the Windows HyperTerminal program, to configure
your PC to communicate with the DNH.
1. Click the Start button, and from the Program menu locate the
HyperTerminal Icon.
2. Click
the
HyperTerminal icon to start the Program.
The Connection Description dialog box will open.
3. In
the Name field, type in a Connection Name. Example: Advance
DataNET Hub.
4. In
the
Icon field select an Icon to represent the name selected.
