DataNET Hub Specifications, Continued
DataNET Option, Standard
Cable • Cable connection by Belden 9182 (single pair) or Belden
SSD1743 (two pairs) or equivalent; two pairs of wires are re-
quired to support redundancy
• Two pairs of cable is required to support redundancy
• Shielded cable or unshielded cable in conduit is required for
conformance to CE certified installation
• Two part connectors with screw-terminals provided for field con-
nection
DataNET Option, Fiber Optic
Cable • Fiber optics connection by 62.5 multi-mode cable corresponding
to 10BaseFL Ethernet specification
• Two pairs of fibers are required to support redundancy
• Type ST mating connectors provided for field connection
• Approximately 3 mbps base transmission rate; uses dedicated
transmission technique that does not require collision detection to
achieve high data throughput efficiency
Fiber Optic Coupler Two (Tx, Rx) ST-Style Connectors
Ethernet Option Each Hub half has an Ethernet connector but only the ‘A’ Hub half is
active.
• Cable connection by 10BaseT (twisted pair) AT&T D-inside wire
(DIW & PDS, IBM Type 3, Category 3 or 5 data ) cable
• Shielded cable or unshielded cable in conduit is required for
conformance to CE certified installation
• 8-pin RJ-45 connector (female) provided
• 10 mbps standard Ethernet
• Maximum length to adapter concentrator/hub 100m (328 ft)
Serial Port • Standard RS-232 port for attachment of a laptop computer, for
configuring DNH IP Addresses and troubleshooting.
