34” Grass Mulcher kit
63 TP 400-2035-00-CO-SMA
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
* Available as optional leaf shredder kit, Part No. 1686609 which contains 8 ea of Ref# 1 & 6. If using with-
out mulcher kit, Ref #2 needs to be ordered
The above parts group applies to the following Mfg. Nos.:
1692470 34” Grass Mulcher Kit
1 1707684* 8 SHREDDERS, Leaf (Optional)
2 1708866 1 BAFFLE, Discharge
3 1708867 1 BAFFLE, Mulching
4 1917356 7 LOCKWASHER, 5/16
5 1917372 7 NUT, Hex, 5/16-18
6 1919438* 8 NUT, Hex, Plastite, 5/16-18 (Optional)
7 1931333 4 CARRIAGE BOLT, 5/16-18 X 3/4
