34” Mower Deck - Drive & Arbor
59
TP 400-2035-00-CO-SMA
REF NO.
PART NO.
QTY.
DESCRIPTION
The above parts group applies to the following Mfg. Nos.:
1692545
34” Mower Deck
1692546
34” Mower Deck
1
1714419
2
NUT, Hex, Flange, 9/16-18
2
1713675
4
WASHER, Belleville
3
1713091
1
PULLEY, 5”
4
1713614
1
HUB, Pulley, 1-35/64”
5
1713199
2
COVER, Arbor Housing Assy.
6
1705897
4
BEARING
7
1713204
2
SPACER
8
1707335
2
GASKET, Foam
9
1713338
2
ARBOR HOUSING ASSY. (Incl. Ref. No. 10)
10
1704314
2
FITTING, Grease
11
1713619
2
WASHER
12
164213
1
SPRING
13
1921972
1
CAPSCREW, 3/8-16 x 2-1/2
14
1924940
2
WASHER, Flat, 3/8
15
1704926
1
PULLEY, Idler, Backside
16
1667812
1
SPACER
17
1916965
1
LOCKWASHER, 3/8
18
1916950
1
NUT, Hex, 3/8-16
19
1930645
1
NUT, Hex, Flange, 2-Way, 3/8-16
20
1928957
1
CAPSCREW, Hex, 3/8-16 x 2-3/4
21
1657242
1
SPACER
22
1665835
1
GRIP, Lever
23
1708561
1
LEVER ASSY.
24
1924356
2
WASHER, Flat, 3/8
25
1719819
1
V-BELT
26
1713090
1
PULLEY, 3-3/4”
27
1713613
1
HUB, Pulley, 1-3/16”
28
1713609
1
SHAFT, Arbor, 5-53/64”
29
1713196
2
SHIELD, Grass, Lower
30
1706737
1
BLADE, 14-27/64”
31
1713089
2
WASHER, Hex
32
1656916
2
WASHER, Spring
33
923471
2
CAPSCREW, Hex, 7/16-14 x 1-1/4, Gr. 8
34
1664847
12
SCREW, Taptite, 5/16-18 x 3/4
35
1928352
1
NUT, Hex, 3/8-16
36
1713610
1
SHAFT, Arbor, 6-33/64”
37
1706738
1
BLADE, 19-29/32”
