Electrical group - briggs & stratton models – Simplicity CORONET 400 User Manual
Page 27
25
TP 400-2035-00-CO-SMA
Electrical Group - Briggs & Stratton Models
1
1715956
1
CLIP
2
1708644
1
WIRE ASSY., Neutral Switch (Gear Models)
3
1704873
2
CLAMP, Wire (1692748, 1692750, 1692819, 1692821, & 1692823 Only)
3
1704873
1
CLIP
4
1676648
1
GROMMET
5
1929477
2
SCREW, Taptite, #10-20 x 5/8 (Gear Models)
6
1708558
1
SWITCH, Neutral (Gear Models)
7
1709250
1
WIRE ASSY, Neutral Switch (Hydro Models)
8
1701580
1
SWITCH, Neutral Start (Hydro Models)
9
1713637
1
ADAPTOR PLUG, Engine (Hydro Models)
10
122023
3
COVER, Terminal
11
1920263
2
NUT, Hex, 5/16-24
12
1917356
2
LOCKWASHER, 5/16
13
1709088
1
CABLE, Solenoid to Starter
14
1685290
1
SOLENOID
15
1665237
1
WIRE ASSY.
16
1713642
1
MODULE, Interlock
17
1665238
1
CIRCUIT BREAKER
18
1925003
2
SCREW, Hex, Flange, Taptite, 1/4-20 x 1/2
19
1667805
1
BRACE, Battery
20
1665872
1
STRAP, Battery
21
1685215
1
BATTERY
22
1612103
1
TUBE, Vent
23
1704581
1
VENT CAP, Battery
24
1923341
2
CAPSCREW, Hex Hd., 1/4-20 x 3/4
25
1921319
2
WASHER, Plain
26
1920427
1
LOCKWASHER, External Tooth, 3/8
27
1916950
1
NUT, Hex, 3/8-16
28
1713163
1
CABLE, Battery, Ground
29
1916964
2
LOCKWASHER, 1/4
30
1916622
2
NUT, Hex, 1/4-20
31
1709086
1
BOOT, Insulator
32
1603618
1
CABLE, Battery to Solenoid
33
1708882
1
WIRE ASSY., PTO Clutch
34
1714054
2
KEY, Ignition
35
1714055
1
ADAPTER, Nut
36
1960547
1
WASHER, Internal Tooth, 5/8
37
1686637
1
SWITCH, Ignition (Including Ref 34 & 36)
38
1716332
1
SWITCH, PTO, Electric Clutch
39
1713499
1
WIRING HARNESS
40
1701011
4
TIE, Self-Locking
41
1919438
2
NUT, Hex, Nylon Lock, 5/16-18 (1692748, 1692750, 1692819, 1692821, &
1692823 Only)
42
1704379
1
SWITCH, Seat (1692748, 1692750, 1692819, 1692821, & 1692823 Only)
42
1714320
1
SWITCH, Seat (1693030, 1693032, 1693034, 1693036, 1693042, 1693044,
1693048 Only)
43
153010
2
SPRING
44
161176
2
SPRING
45
1924940
2
WASHER, Flat, 13/32 x 7/8 x 5/64
46
1922127
2
CAPSCREW, Hex Hd., 5/16-18 x 1-3/4
47
1708552
1
PLATE, Seat Actuator
REF NO.
PART NO.
QTY.
DESCRIPTION
The above parts group applies to the following Mfg. Nos.:
1692748
Coronet, 11HP Gear
1692750
Coronet, 13HP Hydo
1692819
411G, 11HP Gear
1692821
412H, 12HP Hydro
1692823
2411G, 11HP Gear
1693030
Coronet, 11HP Gear
1693032
Coronet, 11HP Gear (Exp)
1693034
Coronet, 13HP Hydro
1693036
Coronet, 13HP Hydro (Exp)
1693042
411G, 11HP Gear
1693044
413H, 12HP Hydro
1693048
2411G, 11HP Gear
