Simplicity CORONET 400 User Manual
Page 39
37
TP 400-2035-00-CO-SMA
Transmission & Carrier - Hydro-Gear 311-0500 Models
1
1709232
1
CARRIER ASSY.
2
1930591
1
SCREW, Hex, Whizlock, 5/16-18 x 3/4
3
1921176
2
CAPSCREW, Hex Hd., 1/2-13 x 1-1/4
4
1924361
1
WASHER, Plain, 17/32 x 1-1/4 x 5/64
5
1719725
1
BUSHING, Rear
6
1930644
2
NUT, Hex, Flange Lock, 1/2 x 13
7
1927557
2
NUT, Hex, Flange Whiz, 5/16-18
8
1709216
1
STRAP, Torque
9
1931332
1
CARRIAGE BOLT, 5/16-18 x 5/8
10
1935159
1
CAPSCREW, Hex, 5/16-18 x 2-1/4
11
1960509
1
SCREW, Taptite, #10-24 x 1-1/4
12
1960151
1
WASHER, Plain, 1/4 x 1-1/4 x 5/64
13
157127
1
SPRING
14
960210
1
WASHER, Plain, 13/32 x 1-1/4 x 1/16
15
1709271
1
LEVER, Release
16
1709901
1
SPACER
17
1920397
1
NUT, Hex, Lock, 1/4-20
18
1713441
1
STRAP, Torque
19
1919381
2
WASHER, 5/16
20
1935048
2
NUT, Flange, 2-Way Lock, 5/16-18
21
1933689
1
SCREW, Hex, Whizlock, 5/16-18 x 1-1/2
22
1686615*
1
TRANSMISSION, Hydro (HydroGear, Mod 311-0500)
23
159106
1
SPRING, Return
24
960478
4
SCREW, Taptite, 5/16-18 x 2-1/4
25
1709323
1
V-BELT
26
1704419
2
BELT STOP
27
1709218
1
PULLEY, Engine
28
171241
1
KEY
29
1709213
1
PULLEY, Transmission
30
1916966
1
LOCKWASHER, 1/2
31
1919262
1
NUT, Hex, Jam, 1/2-20
32
918454
1
COTTER PIN, 1/8 x 1-1/2
33
1654565
2
WASHER, Belleville, 1/2
34
1719683
1
BUSHING, Front
REF NO.
PART NO.
QTY.
DESCRIPTION
Footnotes:
* Service parts are listed on pages 42-45
The above parts group applies to the following Mfg. Nos.:
1692750
Coronet, 13HP Hydo
1692821
412H, 12HP Hydro
1693034
Coronet, 13HP Hydro
1693036
Coronet, 13HP Hydro (Exp)
1693038
Coronet, 14HP Hydro
1693040
Coronet, 14HP Hydro (Exp)
1693044
412H, 12HP Hydro
1693046
414H, 14HP Hydro
1693050
2414H, 14HP Hydro
