Simplicity CORONET 400 User Manual
Page 37
35
TP 400-2035-00-CO-SMA
Transmission Service Parts - Peerless 915-016D
49
778125
1
GEAR, Spur (35 Teeth)
50
778250
1
GEAR, Spur (27 Teeth)
51
778122A
1
GEAR, Spur (22 Teeth)
52
778321
1
GEAR, Spur (19 Teeth)
54
778263
1
GEAR, Spur (11 Teeth)
56
778151
1
GEAR, Spur (15 Teeth)
57
778249
1
GEAR, Spur (23 Teeth)
58
778128A
1
GEAR, Spur (28 Teeth)
59
778129A
1
GEAR, Spur (30 Teeth)
61
778265
1
GEAR, Spur (34 Teeth)
63
786155A
1
SPACER
65A
780160
2
WASHER, Thrust
65
780162
1
WASHER, Thrust
66
776299
1
SHAFT, Input (3-5/16” Long)
67
776352
1
SHAFT, Brake (4 Keyed)
69
780161
1
WASHER, Thrust
71
788069
1
SEAL, Square Cut
76
780090
3
WASHER
77
788078A
1
RING, Retaining, Inverted
79
792144
1
SPRING, Brake
85
792137
2
FITTING, Lubrication
90
788067B
1
GREASE, 32 Oz. Bottle
150
510334
1
GASKET ELIMINATOR (Loctite #515)
161
776302
1
IDLER ASSY., Reverse
174
780085
1
BEARING, Needle
REF NO.
PART NO.
QTY.
DESCRIPTION
Footnotes:
Order parts listed on this page from your local authorized Peerless/Tecumsen Distributer
The above parts group applies to the following Mfg. Nos.:
1692748
Coronet, 11HP Gear
1692819
411G, 11HP Gear
1692823
2411G, 11HP Gear
1693030
Coronet, 11HP Gear
1693032
Coronet, 11HP Gear (Exp)
1693042
411G, 11HP Gear
1693048
2411G, 11HP Gear
