43
TP 400-2035-00-CO-SMA
Transmission Service Parts - Hydro-Gear 311-0500 Models
1
1715164
21
BOLT, 1/4-20 x 1-3/8
2
1715182
1
HOUSING, Lower
3
1715157
1
OIL FILTER ELEMENT
5
1715165
2
PIN
6
1715149
1
SHAFT, Motor
7
1715156
2
WASHER
8
1715155
1
RING, Retaining
9
1715154
1
SEAL-LIP .26 x .42 x .8
10
1715159
1
BRAKE ROTOR/STATOR KIT
11
1715158
1
BOLT, 5/16-18 x 1-3/4
12
1709919
1
NUT, Hex, Lock, 5/16-24
13
1714808
1
COMPRESSION SPRING
14
1709915
2
PIN-ACTUATING
15
1709916
1
ARM-ACTUATING
16
1924874
3
WASHER, 7/16 x 7/8 x 1/16
17
1714431
1
CASTLE NUT, 5/16-24
18
1918447
1
COTTER PIN
20
1715152
1
ACTUATOR-BYPASS
21
1715233
1
BYPASS PLATE
22
1715151
1
BLOCK-CYLINDER (MOTOR) ASSY.
23
1715150
1
BEARING, Thrust .42 x .68 x .16
24
1715797
1
CENTER SECTION ASSEMBLY
25
1715170
2
SEAL, Wiper
26
1715181
2
SLEEVE BEARING
27
1715162
2
SEAL 3/4 x 1-1/4 x 1/4
28
1715180
2
WASHER-3/4 x 1.5 x .13
29
1715179
1
DIFFERENTIAL ASSEMBLY
30
1715146
1
BLOCK-CYLINDER PUMP ASSY.
31
1715171
1
SPRING, Block
32
1715172
1
WASHER, Block Thrust
33
1715163
1
SHAFT, Input
34
1715178
1
NUT-HEX LOCK 5/16-24
35
1714740
1
SPACER
36
1714739
1
SPRING
37
1714737
2
PUCK, Dampener
38
1714738
1
ARM, Control
39
1706175
1
SEAL-LIP
40
1714741
1
STUD, 5/16-24
41
1709910
1
SET SCREW
43
1715142
1
BEARING, Shaft Ball
44
1715141
1
RING-WIRE, Retaining
45
1706174
1
RING, Retaining
46
1706173
1
SEAL-LIP
47
1709921
1
SEAL-LIP 1.0 x .25 x .7
48
1709922
1
RING, Retaining
REF NO.
PART NO.
QTY.
DESCRIPTION
The above parts group applies to the following Mfg. Nos.:
1692750
Coronet, 13HP Hydo
1692821
412H, 12HP Hydro
1693034
Coronet, 13HP Hydro
1693036
Coronet, 13HP Hydro (Exp)
1693038
Coronet, 14HP Hydro
1693040
Coronet, 14HP Hydro (Exp)
1693044
412H, 12HP Hydro
1693046
414H, 14HP Hydro
1693050
2414H, 14HP Hydro
