Simplicity CORONET 400 - Manual (Page 22)

20 TP 400-2035-00-CO-SMA © Copyright 1999 Simplicity Manufacturing, Inc. All Rights Reserved.
Engine Group - Briggs & Stratton Models
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
The above parts group applies to the following Mfg. Nos.:
1692748 Coronet, 11HP Gear
1692750 Coronet, 13HP Hydo
1692819 411G, 11HP Gear
1692821 412H, 12HP Hydro
1692823 2411G, 11HP Gear
1693030 Coronet, 11HP Gear
1693032 Coronet, 11HP Gear (Exp)
1693034 Coronet, 13HP Hydro
1693036 Coronet, 13HP Hydro (Exp)
1693042 411G, 11HP Gear
1693044 413H, 12HP Hydro
1693048 2411G, 11HP Gear
1
2
3
4
5
6
7
8
9
10
11
12
14
3
3
15
11
12
14
3
16
17
24 24
20
21
23
22
27
3
25
26
28
29
3
4
2
9 31
17
3
2
30
32
33
34
5
35
36
37
2
13
18
19
Torque (4) engine
mounting bolts ref#
15, 17, & 24
to 28-34 ft. lbs.
Torque capscrew
ref# 22 to 45-50 ft. lbs.
