30” mower deck - drive & arbor – Simplicity CORONET 400 User Manual
Page 55
53
TP 400-2035-00-CO-SMA
30” Mower Deck - Drive & Arbor
1
1719746
1
V-BELT
2
1714419
1
CAPSCREW, 7/16-14 x 1-1/2 Gr. 8
3
1713675
2
WASHER, Belleville
4
1713092
1
PULLEY
5
1713613
1
HUB, Pulley, 1-3/16”
6
1960373
6
SCREW, Hex, Taptite, 5/16-18 x 1
7
1677274
1
ADAPTER, Arbor
8
1707335
1
GASKET, Foam
9
1713338
1
ARBOR HOUSING ASSY. (Incl. Ref. No. 10)
10
1704314
1
FITTING, Grease
11
1705897
2
BEARING
12
1713204
1
SPACER
13
1713199
1
COVER, Arbor Housing
14
1713619
1
WASHER, Cupped
15
1713609
1
SHAFT, Arbor, 5-53/64”
16
1713196
1
SHIELD, Grass, Lower
17
1664019
1
BLADE, Mower, 30”
18
1713089
1
WASHER, Hex
19
1656916
1
WASHER, Spring
20
923471
1
CAPSCREW, Hex, 7/16-14 x 1, Gr. 8
21
1923903
1
CAPSCREW, Hex, 3/8-16 x 3
22
1924356
2
WASHER, Flat, 3/8 x 1-1/2 x 1/8
23
1715435
1
SPRING
24
1669105
1
SPACER
25
1708562
1
LEVER ASSY.
26
1924940
2
WASHER, Plain, 3/8
27
1707435
1
PULLEY ASSY., Idler, Fixed, 6” Dia.
28
1928352
1
NUT, Hex, Whizlock, 3/8-16
29
1665835
1
GRIP, Lever
30
1923701
1
CAPSCREW, Hex, 3/8-16 x 2
31
1922755
3
WASHER, Flat, 13/32 x 1 x 1/8
32
1704926
1
IDLER PULLEY, Backside
33
1916965
1
LOCKWASHER, 3/8
34
1916950
1
NUT, Hex, 3/8
35
1928731
1
NUT, Hex, Lock, 3/8-16
REF NO.
PART NO.
QTY.
DESCRIPTION
The above parts group applies to the following Mfg. Nos.:
1692543
30” Mower Deck
1692544
30” Mower Deck
