Page 33
31
TP 400-2035-00-CO-SMA
Transmission Controls - Gear Models
REF NO.
PART NO.
QTY.
DESCRIPTION
The above parts group applies to the following Mfg. Nos.:
1692748
Coronet, 11HP Gear
1692819
411G, 11HP Gear
1692823
2411G, 11HP Gear
1693030
Coronet, 11HP Gear
1693032
Coronet, 11HP Gear (Exp)
1693042
411G, 11HP Gear
1693048
2411G, 11HP Gear
1
159106
1
SPRING, Return
2
1919326
4
WASHER, Plain
3
1918447
6
COTTER PIN, 3/32 x 3/4
4
1716035
1
ROD, Clutch, Rear
5
1706256
1
ROD, Brake
6
1709097
1
SPRING, Compression
7
1960044
1
WASHER, 5/16 x 1-1/4 x 1/16
8
1919438
2
NUT, Hex, Nylon Lock, 5/16-18
9
1924359
2
WASHER
10
1707209
1
ROD, Shift, Front
11
1960223
1
CARRIAGE BOLT, 5/16-18 X 1-1/4
12
1710437
2
SPACER
13
1919381
3
WASHER, Plain, 5/16
14
1707210
1
BAR, Shift, Rear
15
1931335
1
CARRIAGE BOLT, 5/16-18 x 1
16
1922234
1
SCREW, Hex Hd., 1/4-28 x 5/8
17
1916964
1
LOCKWASHER, 1/4
18
1921319
1
WASHER, Plain, 17/64 x 5/8 x 3/64
19
1706388
1
BRACKET, Shift
20
1917356
2
LOCKWASHER, 5/16
21
1917372
2
NUT, Hex, 5/16-18
22
1703805
1
KLIPRING, 1/2
23
1924361
2
WASHER, Plain, 1/2
24
1931342
1
CARRIAGE BOLT, 5/16-18 x 2-3/4
25
1708366
1
TORSION BAR
26
1708367
2
BRACKET, Torsion Bar
27
1924856
4
SCREW, Hex Hd., Flange, Taptite, 5/16-18 x 1/2
28
1709345
1
SPACER, Pivot
29
1709221
2
CLEVIS, Idler, Bracket
30
1714062
1
SPRING, Idler
31
1921333
1
SCREW, Hex Hd., Flange, Taptite, 1/4-20 x 5/8
32
1706252
1
LEVER, Idler, Pulley
33
1668827
1
PULLEY, Idler
34
1930645
1
NUT, Hex, Flange Lock, 3/8-16
35
1709850
1
TUBE, Plastic
36
1708554
1
KLIP RING, 3/8
37
1708409
1
PIVOT, Brake
38
1706260
1
ROD, Clutch, Front
39
1709231
1
PIVOT SHAFT ASSY.
40
1706264
1
LEVER, Clutch
41
1704849
1
PAD, Pedal
