Simplicity CORONET 400 User Manual
Page 11
9
TP 400-2035-00-CO-SMA
Frame & Fuel System - Later 11HP Gear, 12HP Hydro, & 13HP Hydro
1
1921333
2
CAPSCREW, Hex Hd., 5/16-18 x 1
2
1925003
6
SCREW, Hex Hd., Taptite, 1/4-20 x 1/2
3
1715962
1
SHROUD, Rear (All Except 1693030, 1693032, & 1693042)
3
1718298
1
SHROUD, Rear (1693030, 1693032, & 1693042 Only)
4
1931277
7
NUT, Hex, Flange, Whizlock, 5/16-18
5
1708363
1
SUPPORT, Fuel Tank
6
1931333
1
CARRIAGE BOLT, 5/16-18 x 3/4
7
1708362
1
STRAP, Fuel Tank, Brace
8
1714020
1
CAP, Fuel Tank, Vented
9
1685483
1
TANK, Fuel
10
1710437
1
SPACER, 21/64 x 1/2 x 21/64
11
1924940
1
WASHER, Plain, 13/32 x 7/8 x 5/64
12
1960373
3
SCREW, Taptite, 5/16-18 x 1
13
1654930
1
BUSHING, Rubber
14
1674231
1
ELBOW
15
1960112
2
CLAMP, Hose
16
1718678
1
HOSE, Fuel Line
17
173206
1
FILTER, Fuel
18
1933988
2
PAL NUT, 5/16
19
1930591
8
CAPSCREW, Hex Hd., Whizlock, 5/16-18 x 3/4
20
1708525
1
PAD, Foot Rest, LH
21
176440
4
BUSHING
22
1660007
1
FRAME ASSY. (Incl. Ref. No. 2)
23
1708524
1
PAD, Foot Rest, RH
24
1704351
14
FASTENER
25
1708253
1
PANEL, Front (1693030, 1693032, 1693042 Only)
25
1718376
1
PANEL, Front (All Except 1693030, 1693032, 1693042)
26
1935255
4
PAL NUT, 5/16-18
27
1718841
1
SUPPORT, “U”, Seat
28
1715970
2
BUMPER, Rubber
29
1924856
1
SCREW, Hex Hd., Taptite, 5/16 x 1/2
30
1708725
1
DUCT, Air Inlet
31
1704626
2
SPACER, Plastic
32
1705249
2
SPACER
33
1704628
2
PIN, Quick
34
1705248
2
PIVOT, Hood
35
921133
2
FITTING, Lube
36
1919381
4
WASHER, Plain
37
1930591
2
CAPSCREW, Hex Hd., 5/16-18
38
1917372
1
NUT, 5/16-18
39
1921977
2
CAPSCREW, 5/16-18 x 1-1/4
40
1703900
1
SPACER
41
960208
2
WASHER, 1”
42
1708881
1
CAP, Black, Vinyl
43
1708509
1
ADJUSTER, Seat
REF NO.
PART NO.
QTY.
DESCRIPTION
The above parts group applies to the following Mfg. Nos.:
1692748
Coronet, 11HP Gear
1692750
Coronet, 13HP Hydo
1692819
411G, 11HP Gear
1692821
412H, 12HP Hydro
1692823
2411G, 11HP Gear
1693030
Coronet, 11HP Gear
1693032
Coronet, 11HP Gear (Exp)
1693034
Coronet, 13HP Hydro
1693036
Coronet, 13HP Hydro (Exp)
1693042
411G, 11HP Gear
1693044
413H, 12HP Hydro
1693048
2411G, 11HP Gear
