C-1

A

PPENDIX

C

S

PECIFICATIONS

Physical Characteristics

Ports
24 100BASE-FX fiber
1 slot for an optional media expansion module
1 slot for an optional media expansion module or stacking module

Network Interface
100BASE-FX: VF-45 connector

Multimode fiber cable; 62.5/125 or 50/125 microns

Stack Interface
Connects up to 4 units

4.8 Gbps, full duplex, uplink/downlink ports
9.6 Gbps stack backplane bandwidth

Buffer Architecture
32 Kbytes per 100 Mbps ports
2 Mbytes per 1000 Mbps ports

Aggregate Bandwidth
8.8 Gbps

Switching Database
8K MAC address entries

LEDs
System: Power, RPU, Mgmt
Port: Mode (flow control, full duplex, activity),
Link (speed, link, disable/partition)
