Registering Local Information
C
h
a
p
te
r 2:
R
e
gi
s
tr
a
tio
n
an
d Se
tu
p
fo
r Sy
s
tem
A
d
m
in
is
tr
a
to
rs
Enter the same LDNs in the A1 and A2
(B1 and B2, C1 and C2, depending on
the number of lines you use) text boxes.
When you use the NTI DMS-100
(National ISDN) or NTI DMS-100
(Custom ISDN) switch type
Enter the different LDNs in the A1 and
A2 (B1 and B2, C1 and C2, depending
on the number of lines you use) text
boxes. These switch types are given a
separate number for each channel.
When you use the AT&T 5ESS
(National ISDN) switch type
You may enter the same or different
numbers in two channels.
4
Open Page 6 (SPID setup menu) to
enter the SPID.
The SPID generally comprises 12 digits,
including a 7 digit LDN (Local
Directory Number).
Be sure to enter the different SPID
number in each of the A1 and A2 (B1
and B2, C1 and C2, depending on the
number of lines you use) text boxes if
you have entered the separate LDNs in
the Local Number text boxes for each
channel in step 3.
For the AT&T 5ESS (National ISDN)
and AT&T 5ESS (Multipoint Custom
ISDN) switch type
Enter the SPID in the A1 text box only.
For the NTI DMS-100 (National
ISDN), NTI DMS-100 (Custom
ISDN), AT&T 5ESS (National ISDN)
switch type
Enter the different SPID numbers in the
A1 and A2 text boxes.
For the AT&T 5ESS (Point-to-Point
Custom ISDN) switch type
You do not need to set up the SPID, then
no entry in the A1 and A2 (B1 and B2,
C1 and C2, depending on the number of
lines you use) is required.
If you connect 4-6 ISDN lines, the D1-F2
text boxes are shown in Page 3 and Page 7
of the ISDN Setup menu. Fill in the boxes
following steps 3 and 4.
5
After the settings are completed,
select “Save”, then press the PUSH
ENTER button.
Page: 2/7
ISDN Setup
Save Cancel
A2
A1
Area Code Local Number
B1
B2
C1
C2
408 9876532
408 9876532
Auto SPID
Page: 2/7
ISDN Setup
Save Cancel
A2
A1
Area Code Local Number
B1
B2
C1
C2
408 9876543
408 9876544
Auto SPID
Note
Page: 6/7
ISDN Setup
Save Cancel
A2
A1
SPID
019876532001
B1
B2
C1
C2
Page: 6/7
ISDN Setup
Save Cancel
A2
A1
SPID
019876543001
019876544001
B1
B2
C1
C2
