198
Specifications
PCS-P1/P1P Communication Terminal (RGB OUT)
PCS-DSB1 Data Solution Box (RGB IN A/RGB IN B)
Acceptable RGB Input/Output Signals
Picture element Signal format fH (kHz) fV (Hz) Dot clock
(MHz) Sync
1024 × 768 XGA VESA 60 Hz 48.363 60.004 65 H-neg V-neg
element Signal format fH (kHz) fV (Hz) Dot clock
(MHz) Sync
640 × 480 VGA mode 31.469 59.94 25.17 H-neg V-neg
Macintosh 13” 35 66.667 30.24 H-neg V-neg
VGA VESA
72 Hz 37.861 72.809 31.5 H-neg V-neg
VGA VESA
75 Hz 37.5 75 31.5 H-neg V-neg
VGA VESA
85 Hz 43.269 85.008 36 H-neg V-neg
800 × 600 SVGA VESA
56 Hz 35.156 56.25 36 H-pos V-pos
SVGA VESA
60 Hz 37.879 60.317 40 H-pos V-pos
SVGA VESA
72 Hz 48.077 72.188 50 H-pos V-pos
SVGA VESA
75 Hz 46.875 75 49.5 H-pos V-pos
SVGA VESA
85 Hz 53.674 85.061 56.25 H-pos V-pos
1024 × 768 XGA VESA
60 Hz 48.363 60.004 65 H-neg V-neg
XGA VESA
70 Hz 56.476 70.069 75 H-neg V-neg
XGA VESA
75 Hz 60.023 75.029 78.75 H-pos V-pos
