30 Using the EDS Mode
Selecting a switch
❏
While in the EDS Modes (EDS-1 or EDS-2), use the control panel’s
SWITCH button to select a bank switch. While the SW indicator is
flashing, the lit indicator indicates the currently selected switch.
Changing a switch setting
❏
After selecting a bank and switch, press the control panel’s ON/OFF
button to turn the switch on and off. The current setting of the switch is
shown by the
ON LINE indicator: the indicator is lit when the switch is on,
and is not lit when the switch is off.
Printing the current switch settings
❏
In the EDS Modes, press and hold the control panel’s PRINT button to
print out the current switch settings. Asterisks on the printout show whether
a switch is turned on or off.
Exiting the EDS Modes
❏
Press the control panel’s EXIT button to exit the EDS Modes.
EDS Modes Settings
The following details all of the settings you can program in the EDS Mode.
Lit Indicator Selected Switch
A1 1
B2 2
C3 3
D4 4
E5 5
F6 6
