14 Printer Setup
Printing on fanfold paper
When printing on fanfold paper, take care not to print too close to the
perforations that separate each sheet. The following shows the recommended
print area for fanfold paper, cut-sheet paper, Labels and Envelope.
4 mm (0.16") *1
18 mm
First page
Last page
18 mm
(0.7")
4 mm (0.16")
4 mm (0.16")
117 mm (4.6")
Bottom of
Form
Perforation
Perforation
Cut-sheet paper
5 mm
4 mm (0.16")
5 mm
4 mm (0.16")
(0.2")
(0.2")
(0.7")
4 mm (0.16")
4 mm (0.16")
Fanfold paper
2.54 mm (0.1") min.
12.7 mm
(0.5") min.
Labels
Label
C
C
C
C
C : 2.54 mm (0.1") min.
12.7 mm
(0.5") min.
Perforation
Envelope
*1 : When stapled multi-part paper with
a width of less than 4.5 inches is used,
the print area is 37 mm from the edge
of the paper.
25.4 mm
36 mm (1.42")
25.4 mm (1")
4 mm (0.16")
(1")
