RS232C CONTROL
COMMAND TABLE (TABLE 4)
The commands available are indicated in the table.
If a function is not available on the unit, the command will not operate even if sent.
0 1 2 3 4 5 6 7 8 9
0 0 ENTER LIVE FULL 1
1 1 VCR PB FULL 2
2 2 VERSION (MULTI) FULL 3
3 3 » « SHIFT QUAD FULL 4
4 4 1 O MENU PLUS
5 5 + NEXT ZOOM
6 6 CLEAR – EXIT STILL
7 7 SEQ.
8 8 MON 2
9 9 SECURITY LOCK ON
A ACK SECURITY LOCK OFF
B NAK (POWER ON/OFF)
C (SET ON)
D (SET OFF)
E
F
A B C D E F
0 CLK. ADJ.
1 MENU RESET
2
3
4
5 ALARM STATUS SENSE
6
7 STATUS SENSE
8
9
A
B
C
D
E
F ALARM
