LIVE PICTURE MODE
Press the LIVE button.
The live pictures from the cameras connected to the CAMERA IN terminals on the unit back
panel will be displayed on monitor 1.
Refer to the diagrams below for the buttons to press in order to select the desired operation
mode.
If recording, the signal at the VCR OUT terminal will switch according to the selected
operation mode.
Please refer to (VCR SET) on page 31, for more information on settings for recording.
MONITOR 1 DISPLAYS AND FUNCTIONS
MONITOR 2 DISPLAYS AND FUNCTIONS
LIVE
LIVE
Monitor 1
(4 divisions split screen)
(Still image)
STILL 4
(P10)
(Zoomed in image)
ZOOM 4
(P10)
(Automatic sequential display)
SEQUENCE
(P14)
(Full screen)
1
(P12)
(Still image)
(Zoomed in image)
STILL
ZOOM
(Zoomed in still image)
STILL
STILL
0 1 s
zz sz sz
ZOOM 4
(P11)
4
(Zoomed in still image)
(Zoom range setting)
(Zoom)
(P12)
(P11, 12)
QUAD
Monitor 2
(Automatic sequential display)
MON 2 3 SEQUENCE
(Automatic sequential display)
(Full screen)
L8FH5/US (MPX-CD4 GB) 1999. 6. 4
English 9
