LAN1/2 (Ethernet Ports)
Two Ethernet ports (designated LAN1
and LAN2) are located beside the VGA
port on the I/O backplane. These ports
accept RJ45 type cables.
Power LED
The Power LED connector is desig-
nated JLED. Connect an LED here for
indication of power being supplied to
the serverboard. See the table on the
right for pin defi nitions.
Power LED
Pin Defi nitions (JLED)
Pin# Defi nition
1 +5V
2 Key
3 Ground
