Appendix D: Adaptec HostRAID Setup Guidelines
D-9
Assigning Array Properties
Once a new array is completed, you can assign properties to the array.
Caution: Once the array is created and its properties are assigned, you cannot
change the array properties using this utility.
To assign properties to the new array
1. In the Array Properties menu (shown below), select an array type and press
Enter. Only the available array types will be displayed on the screen.
2. Under the item "Arrays Label", type in a label and press <Enter>. (The label
shall not be more than 15 characters.)
3. For RAID 0, select the desired stripe size. (Available stripe sizes are 16, 32, and
64 KB. 64K is default. Please do not change the default setting.)
4. The item: "Create RAID via" allows you to select between the different ways of
creating methods for RAID 0 and RAID 1.
The following table gives examples of when each is appropriate.
Note: If you select Migrate for RAID 0, or Build for RAID 1, you will be asked
to select the source drive. The contents of the source drive will be preserved.
However, the data on the new drive will be lost.
Raid Level Create Via When Appropriate
RAID 0 Quick Init Creating a RAID 0 on new drives
RAID 0 Migrate* Creating a RAID 0 from one new drive and
one drive with data you wish to preserve
RAID 1 Build* Any time you wish to create a RAID 1, but especially if
you have data on one drive that you wish to preserve
RAID 1,
RAID 10 Clear Creating a RAID 1 or RAID 10 on new drives, or when
you want to ensure that the array contains no data after
creation.
RAID 1,
RAID 10 Quick Init Fastest way to create a RAID 1 or RAID 10
Appropriate when using new drives
