C-10

S

UPER

S

ERVER 5015M-UR/5015M-U/5015M-NTR/5015M-NT User's Manual

C-2 Installing Windows XP/2000/2003 for RAID Systems

New Operating System-Windows XP/2000/2003 Installation

a. Insert Microsoft Windows XP/2000/2003 Setup CD in the CD Driver, and the

system will start booting up from CD.

b. Press the key when the message-" Press F6 if you need to install a third

party SCSI or RAID driver" displays.

c. When the Windows XP/2000/2003 Setup screen appears, press "S" to specify

additional device(s).

d. Insert the driver diskette-"Intel AA RAID XP/2000/2003 Driver for ICH7R into Drive

A: and press the key.

e. Choose Intel(R)82801GR/GH SATA RAID Controller from the list indicated in the

XP/2000/2003 Setup Screen, and press the key.

f. Press the key to continue the installation process. (If you need to specify

any additional devices to be installed, do it at this time.) Once all devices are speci-

fi ed, press the key to continue with the installation.

g. From the Windows XP/2000/2003 Setup screen, press the key. The

XP/2000/2003 Setup will automatically load all device fi les and then continue the

Windows XP/2000/2003 installation.

h. After Windows XP/2000/2003 Installation is completed, the system will automati-

cally reboot.

i. Insert Super Micro CD that came with the package into the CD Drive during system

reboot, and the Super Micro Main Screen will appear.

Note: the current version of the ICH7R SATA RAID Utility can only support Windows

XP/2000/2003 Operating Systems.
