D-2
S UPER S ERVER 5015M-UR/5015M-U/5015M-NTR/5015M-NT User's Manual
Confi guring the Adaptec SATA RAID
1. Press the key during system bootup to enter the BIOS Setup Utility.
Note: If this is the fi rst time you power on the system, we recommend that you
load the Optimized Default Settings. If you have already done so, please skip to
Step 3.
2. Use the arrow keys to select the "Exit" Settings. Once in the "Exit" settings, Scroll
down to select "Load Optimized Default Settings" and press the key. Select
"OK" to confi rm the selection. Press to load the BIOS default setting.
3. Use the arrow keys to select the "Main" section in BIOS.
4. Scroll down to "SATA Control Mode" and press to select "Enhanced"
5. Scroll down to "SATA RAID Enabled" and press . Then, select "En-
abled."
6. Scroll down to "ICH RAID Codebase" and select "Adaptec". Then press .
(For Adaptec ICH RAID confi gurations: Change the setting from Intel to Adaptec.)
7. Scroll down to "Exit". Select "Exit Saving Changes" from the "Exit" menu. Press
the key to save the changes and exit the BIOS.
8. Once you've exited the BIOS Utility, the system will reboot.
9. During the system bootup, press the and keys simultaneously to run
the Intel RAID Confi guration Utility when prompted by the following message: Press
for Adaptec RAID Confi guration Utility.
