5-16
S UPER S ERVER 5015M-UR/5015M-U/5015M-NTR/5015M-NT User's Manual
ATX PS/2 Keyboard and
PS/2 Mouse Ports
The ATX PS/2 keyboard and the PS/2
mouse ports are located beside the
USB ports. See the table on the right
for pin defi nitions.
PS/2 Keyboard and
Mouse Ports
Pin Defi nitions
Pin# Defi nition
1 Data
2 NC
3 Ground
4 VCC
5 Clock
6 NC
Wake-On-LAN
The Wake-On-LAN header is desig-
nated WOL. See the table on the right
for pin defi nitions. You must enable
the LAN Wake-Up setting in BIOS to
use this feature. You must also have
a LAN card with a Wake-on-LAN con-
nector and cable.
Wake-On-LAN
Pin Defi nitions (WOL)
Pin# Defi nition
1 +5V Standby
2 Ground
3 Wake-up
Chassis Intrusion
A Chassis Intrusion header is located
at JL1. Attach the appropriate cable
to inform you of a chassis intrusion.
Chassis Intrusion
Pin Defi nitions (JL1)
Pin# Defi nition
1 Intrusion Input
2 Ground
Speaker Connector
The speaker connector located at J9
allows you to choose between using
the internal or an external speaker.
For the internal speaker, jump pins 3
and 4. To use an external speaker,
place the speaker cable header on all
four pins. See the table on the right.
Speaker Connector
Pin Defi nitions (J9)
Pin Setting Defi nition
Pins 3-4 Internal Speaker
Pins 1-4 External Speaker
