Page 23
Chapter 2: Server Installation
2-7
Figure 2-4. Installing the Server into a Telco Rack
Installing the Server into a Telco Rack
To install the 5015M-UR/5015M-U/5015M-NTR/5015M-NT into a Telco type rack,
use two L-shaped brackets on either side of the chassis (four total). First, determine
how far follow the server will extend out the front of the rack. Larger chassis should
be positioned to balance the weight between front and back. If a bezel is included
on your server, remove it. Then attach the two front brackets to each side of the
chassis, then the two rear brackets positioned with just enough space to accom-
modate the width of the telco rack. Finish by sliding the chassis into the rack and
tightening the brackets to the rack.
