Chapter 3: System Interface
3-3
NIC2: Indicates network activity on LAN2 when fl ashing .
NIC1: Indicates network activity on LAN1 when fl ashing.
HDD: Indicates IDE channel activity. On the SuperServer 5015M-UR/
5015M-U/5015M-NTR/5015M-NT this light indicates SATA and/or DVD-ROM
drive activity when fl ashing.
Power: Indicates power is being supplied to the system's power supply
units. This LED should normally be illuminated when the system is operating.
3-4 SATA Drive Carrier LEDs
Each Serial ATA drive carrier has two LEDs.
Green: When illuminated, the green LED on the front of the SATA drive car-
rier indicates drive activity. A connection to the SATA backplane enables this LED
to blink on and off when that particular drive is being accessed.
Red: The red LED indicates two states. When blinking, it indicates the drive
is rebuilding. When solid, it indicates a drive failure. If a SATA drive fails, you
should be notifi ed by your system management software. Please refer to Chapter
6 for instructions on replacing failed SATA drives.
