1-2
S UPER S ERVER 5015M-UR/5015M-U/5015M-NTR/5015M-NT User's Manual
1-2 Serverboard Features
At the heart of the SuperServer 5015M-UR/5015M-U/5015M-NTR/5015M-NT lies
the PDSMU, a single processor serverboard based on Intel's 3010 chipset. Below
are the main features of the PDSMU (see Figure 1-1 for a block diagram of the
chipset).
Processors
The PDSMU supports a single 775-pin Intel ® Xeon® 3000 Series, Pentium® D,
Pentium Extreme Edition, Pentium 4, and Celeron D processors at a FSB speed
of 1066/667/533 MHz. Please refer to the serverboard description pages on our
web site for a complete listing of supported processors.
Memory
The PDSMU has four 240-pin DIMM sockets that can support up to 8 GB of un-
buffered ECC/non-ECC DDR2-667/533/400 SDRAM. Memory may be installed in
either interleaved or non-interleaved confi gurations. Please refer to Chapter 5 for
details.
UIO (5015M-UR)
The PDSMU is a specially-designed serverboard that features Supermicro's UIO
(Universal I/O) technology. UIO serverboards have a PCI-Express x8 connector
that can support any one of several types of UIO card types to add SAS ports,
additional LAN ports, etc. to the serverboard. This allows the user to tailor the
serverboard to their own needs. Note: the 5015M-UR does not come with a UIO
card installed.
Serial ATA
An on-chip (ICH7R) SATA controller is integrated into the PDSMU to provide a
four-port, 3 Gb/sec Serial ATA subsystem, which is RAID 0, 1, 5 and 10 supported.
The SATA drives are hot-swappable units. Note: The operating system you use
SuperServer 5015M-UR/5015M-U/5015M-NTR/5015M-NT User's Manual
Note: a "V" at the end of the server name indicates the chassis is silver, "B" indicates
black.
