Table B.3 - WANServer Port 2
Table B.4 - WANServer Port 3
VME P2
Connector
DB-25F
Connector
Signal Name Function
A-18 02 XMT-P Transmit Data
C-19 14 XMT-N
A-17 03 RCV-P Receive Data
C-17 16 RCV-N
C-18 15 TSET-P Transmit Clock
C-24 12 TSET-N
C-20 17 RSET-P Receive Clock
A-22 09 RSET-N
A-20 04 RTS-P Request To Send
A-24 19 RTS-N
A-19 05 CTS-P Clear To Send
A-21 13 CTS-N
C-22 06 DCEREADY-P DCE Ready
A-23 22 DCEREADY-N
C-21 20 DTEREADY-P DTE Ready
C-23 23 DTEREADY-N
VME P2
Connector
DB-25F
Connector
Signal Name Function
A-26 02 XMT-P Transmit Data
C-27 14 XMT-N
A-25 03 RCV-P Receive Data
C-25 16 RCV-N
C-26 15 TSET-P Transmit Clock
C-32 12 TSET-N
C-28 17 RSET-P Receive Clock
A-30 09 RSET-N
A-28 04 RTS-P Request To Send
A-32 19 RTS-N
A-27 05 CTS-P Clear To Send
A-29 13 CTS-N
C-30 06 DCEREADY-P DCE Ready
A-31 22 DCEREADY-N
C-29 20 DTEREADY-P DTE Ready
C-31 23 DTEREADY-N
