LBI-38965
B-8
Pwr
SCSI Conn.
Factory Set Jumpers
RA2
RA1
TEAC FD235HS-711
ID2
ID1
ID0
SCSI ID = 1
(Terminators
Removed)
Figure B.7 - Teac FD235HS-711 Floppy Disk
1
2
3
4
5
6
7
8
SW1
JP6
JP4
RD2
RD1
PWR
(Terminators Removed)
SCSI Connector
ON
SCSI ID = 3
Self-Test
Reserved
DDS Pass-Through (Compression Off)
Parity On
SCSI Mode (SCSI-1)
OFF
Figure B.8 - Archive/Maynard 4324NP DAT
