109
Department key positioning
You can assign a department code to each key position. Each key position has a corresponding key number.
Departments may be freely selected for the number of department keys and their positions.
To assign the department to a key position, select the key number of the position.
For key number positions, refer to section “3 Standard key number layout” in chapter “KEYBOARD”.
The key number placement is determined by your local authorized SHARP dealer.
Color Video Monitor (CVM) control character
This programming enables you to assign each department with a number that can be used as a CVM control
character. This number is converted to a two-digit character code that is transmitted for use with a CVM device.
Programming 16 as CVM control character for department 1
Character code converted
2158 . @
1 @ 16 t
Ç
Print Key operation
Example
2158
. @ @ t Ç
Dept. code
(1 - 99)
CVM control character
(0 - 255)
To program any dept.
To program zero
To program for the following dept.
Procedure
2158 PGM 2
Key no.
2119 . @
1 @ 1 t
2 t
Ç
Print Key operation
Example
Note
Procedure
2119 PGM 2
2119
. @ @ t Ç
Key number
(max. 3 digits)
Dept. code
(1 - 99)
To program any key number
Cancellation
To program the next sequential key number
