Sony SA-WFT7 User Manual
Service manual, Home theatre speaker system, Us model canadian model aep model uk model
1
SERVICE MANUAL
US Model
Canadian Model
AEP Model
UK Model
SPECIFICATIONS
Sony Corporation
Home Audio Division
Published by Sony Engineering Corporation
9-879-750-02
2005K04-1
© 2005. 11
HOME THEATRE SPEAKER SYSTEM
SS-FRF7ED
(with WS-FT7)
SA-FT7ED/WFT7/SS-CNF7ED/
FRF7ED/WS-FT7
SS-CNF7ED
AUDIO POWER SPECIFICATIONS (US, CND model)
POWER OUTPUT AND TOTAL HARMONIC DISTORTION:
With 4 ohm loads both channels driven, at 100 Hz; rated 250
watts per channel minimum RMS power, with no more than
10% total harmonic distortion from 250 milliwatts to rated output.
SS-FRF7ED (front/surround speakers)
Speaker system
2 way, magnetically shielded
Speaker units
Woofer: 10 cm (4 in.), cone
type
Tweeter: 20 mm (
3/4
in.),
dome type
Enclosure type
Bass reflex
Rated impedance
8 ohms
Power handling capacity
Maximum input power:
120 W
Sensitivity level
84 dB (1 W, 1 m)
Frequency range
120 Hz – 70,000 Hz
Dimensions (w/h/d)
Approx. 130
Ч
510
Ч
30 mm
(5
1/8
Ч
20
1/8
Ч
1
3/16
in.)
with floor stand
Approx. 130
Ч
1,100
Ч
30 mm
(AEP, UK model)
(5
1/8
Ч
43
5/16
Ч
1
3/16
in.)
(Diameter of base: 280 mm
(11
1/32
in.))
with table top stand
Approx. 130
Ч
585
Ч
30 mm
(5
1/8
Ч
23
1/8
Ч
1
3/16
in.)
(Diameter of base: 250 mm
(9
7/8
in.))
with wall mounting bracket
Approx. 130
Ч
576
Ч
50 mm
(5
1/8
Ч
22
3/4
Ч
2 in.)
Mass
Approx. 2.0 kg (4 lb 7 oz)
with floor stand
Approx. 7.7 kg (16 lb 15 oz)
(AEP, UK model)
with table top stand
Approx. 3.3 kg (7 lb 4 oz)
with wall mounting bracket
Approx. 2.5 kg (5 lb 9 oz)
SS-CNF7ED (center speaker)
Speaker system
2 way, magnetically shielded
Speaker units
Woofer: 8 cm (3
1/4
in.), cone
type (
×
2)
Tweeter: 20 mm (
3/4
in.),
dome type
Enclosure type
Bass reflex
Rated impedance
8 ohms
Power handling capacity
Maximum input power:
120 W
Sensitivity level
84 dB (1 W, 1 m)
Frequency range
130 Hz – 70,000 Hz
Dimensions (w/h/d)
Approx. 500
Ч
94
Ч
30 mm
(19
3/4
Ч
3
3/4
Ч
1
3/16
in.)
with table top stand
Approx. 500
Ч
108
Ч
66 mm
(19
3/4
Ч
4
3/8
Ч
2
5/8
in.)
with wall mounting bracket
Approx. 500
Ч
94
Ч
42 mm
(19
3/4
Ч
3
3/4
Ч
1
11/16
in.)
• SA-FT7ED is composed of following models.
COMPONENT MODEL NAME
FRONT/SURROUND SPEAKER
SS-FRF7ED
CENTER SPEAKER
SS-CNF7ED
SUBWOOFER
SA-WFT7
SPEAKER STAND
WS-FT7
WS-FT7 is not included in US and Canadian model.
SA-WFT7
SS-FRF7ED
– Continued on next page –
