Sentry Instruction Manual - Version 6
CONFIGURATION PROCEDURE
Page: 41
SENTRY KEY BOARD
Ts = TEST R = RESET M = MODE T = TIME
^ = ARROWS E = ENTER
RESET KEY
* GLOBAL CALIBRATION
Reset Alarms
R E
Gas Type (Concentration)
^
E
Reset System
R R E
Enter to Span
E
Reset History
R R R E
Apply Zero Gas
E
TIME KEY
Enter to Span
E
Check History
T E
Apply Span Gas
E
Printer History
T T E
Operate Mode (After timer)
E
Print System
T T T E
* LOCAL CALIBRATION
Print Status
T T T T E
Gas Type (Concentration)
^ E
Set Date & Time
T T T T T E
Apply Zero & Span
E
TEST KEY
Operate Mode (After timer)
E
Test System
Ts E
* CHANGE MODULE
Test Alarms
Ts Ts E
Module #
^
E
MODE KEY - PASSIVE
Gas Type
^
E
Change/Calib
M E
Module On/Off
^
E
Select Scan
M M E
Low Alarm Latch/Non
^
E
Check Calib
M M M E
High Alarm Latch/Non
^
E
Check Module
M M M M E
High Alarm Value
^
E ^
E ^
E
MODE KEY - ACTIVE
Low Alarm Value
^
E ^
E ^
E
Change/Calib
M E
Scaling Factors
^
E ^
E ^
E
Calibrate
*
E
* SET USER CODE
Change Calibrate
*
M E
User Number
^
E
Change Module
*
M M E
Entry Code
^E ^E ^E ^E
Set User Code
*
M M M E
* CHANGE PRINTER
Change Printer
*
M M M M E
Printer On/Off
^
E
Change Gas Tag
M M M M M E
Controller ID
^^ E
Change Module Tag
M M M M M M E
Status Frequency
^^ E
* CHANGE CALIB
Print History
^
E
Gas Type
^^ E
Gas Type
^^ E
Full Scale
^^ E ^^ E ^^ E
Min. Conc.
^^ E
Calib Concentration
^^ E ^^ E ^^ E
Conc. Change
^^ E
Calib Frequency
^^ E
Gas Type
^
E
Global Calib
^
E
Exit
R
Figure 4-2
Sentry Keyboard - Quick Help
