Made to Order Specifications: Solid State Switch

-50: No Indicator (Dark room) Specifications
-61: Oil Resistant, Flexible Cable Specifications

-50

Without Indicator Light (for dark room specifications)

Possible to use under the environment which hates a light.

50

D

Solid state switch model

61

D

Applicable part no.: General purpose type,

solid state switch
except D-J51

Note) Please consult with

SMC for water
resistant type, timer
equipped type,
output dialysis type,
wide range
detection type,
magnetic field
resistant type, heat
resistant type.

Dimensions and specifications are common as standard products with the exception of no indicator light.

Lead wire length

For lead wire length, refer to page 12-13-5.

Lead wire length

For lead wire length, refer to page 12-13-5.

Without indicator light
(for dark room specifications)

2

Oil Resistant, Flexible Heavy-duty Cord Specifications

3

Solid state switch part no.

Applicable part no: All the solid state

switches with the
exceptance of D-J51,
output diagnostic type,
terminal conduit type,
connector type,
magnetic field resistant
type, heat resistant
type

Note)

A

B

A

B

Oil resistant flexible
cabtire cord is used for
D-Y59 , Y69 ,
Y7P(V) as standard. No
need to suffix -61 to the
end of part number.

Specifications are the same as standard products with the exception of lead wire specifications.
Lead wire: For D-F8, F9 type······ ø2.7, 0.15 mm

2

, 3 cores (Brown, Blue, Black), 2 cores (Brown, Blue)

For other model nos.··················· ø3.4, 0.15 mm

2

, 3 cores (Brown, Blue, Black), 2 cores (Brown, Blue)

Dimensions are identical with D-F5 type, G5 type, J59 type, K59 type. Lead wire diameter is changed from ø4 to ø3.4. In other series products,
it is common as standard product's specifications.

Oil resistant, flexible heavy-duty cord
specifications

Symbol

Symbol

-61

This is the product which uses a heavy-duty cord having flexible characteristics 5 times (SMC
comparison) as strong as oil resistant heavy-duty cord used in the standard products.

12-13-27
