D-Y5

„, D-Y6„, D-Y7P, D-Y7PV (With indicator light)

Auto switch model

Electrical entry direction

Wiring type

Output type

Applicable load

Power supply voltage

Current consumption

Load voltage

Load current

Internal voltage drop

Leakage current

Indicator light

D-Y59A

In-line

3-wire

NPN

IC circuit, Relay, PLC

5, 12, 24 VDC (4.5 to 28 V)

28 VDC or less

40 mA or less

D-Y69A

Perpendicular

D-Y69B

Perpendicular

D-Y7PV

Perpendicular

D-Y59B

In-line

2-wire

24 VDC relay, PLC

24 VDC (10 to 28 VDC)

5 to 40 mA

4 V or less

0.8 mA or less at 24 VDC

D-Y7P

In-line

PNP

10 mA or less

80 mA or less

0.8 V or less

1.5 V or less
(0.8 V or less

at 10 mA load current)

Red LED lights when ON.

100 µA or less at 24 VDC

Auto Switch Specifications

PLC: Abbreviation of Programmable Logic Controller

• Lead wire — Oil resistant vinyl heavy-duty cord, ø3.4, 0.15 mm

2

, 3 cores (Brown, Black, Blue),

2 cores (Brown, Blue), 0.5 m

Note 1) Regarding the common specifications of the solid state switches, refer to page 12-13-5.
Note 2) Regarding the lead wire length, refer to page 12-13-5.

Weight

(g)

Dimensions

Auto switch model

0.5

3

5

D-Y59B D-Y69B

9

50

83

D-Y59A D-Y69A

10

53

87

D-Y7P(V)

10

53

87

Lead wire length

(m)

A

B

A

B

Auto Switch Internal Circuit

D-Y59A, D-Y69A

D-Y59B, D-Y69B

D-Y7P, D-Y7PV

D-Y59A, D-Y7P, D-Y59B

D-Y69A, D-Y7PV, D-Y69B

Grommet

SMC

SMCSMC

6.2

5

2.5

29

ш3.4

12.5

27.3

6.2

5

12.5

8.5

2.5

ш3.4

Most sensitive position

Mounting screw M2.5 x 4

l

Slotted set screw

Slotted set screw

Indicator light

Indicator light

Most sensitive position

Mounting screw M2.5 x 4

l

Solid State Switch
Direct Mounting Style

D-Y59 /D-Y69 /D-Y7P(V)

Main circuit

of switch

Main circuit

of switch

Main circuit

of switch

OUT (

+

)

Brown

OUT (–)
Blue

OUT
Black

DC (

+

)

Brown

DC (

)

Blue

OUT
Black

DC (

+

)

Brown

DC (

)

Blue

For details about certified products
conforming to international standards,
visit us at www.smcworld.com.

12-13-17
