When using the optional board (DVI) “POA-AMDADI”, refer to the chart on the previous page.
When using other optional boards, refer to the charts below.
Supported Signal Format for Optional Board
ON-SCREEN
DISPLAy
RESOLUTION H-Freq.(kHz) V-Freq.(Hz)
D-480i 720x480 15.734 60.000
D-575i 720x576 15.625 50.000
D-1035i 1920x1035 i 33.750 60.000
D-1080i
1920x1080 i 33.750 60.000
1920x1080 i 28.125 50.000
D-720p
1280x720 37.500 50.000
1280x720 45.000 60.000
D-1080psf/24 1920x1080 27.000 48.000
ON-SCREEN
DISPLAy
RESOLUTION H-Freq.(kHz) V-Freq.(Hz)
D-1080psf/25 1920x1080 28.125 50.000
D-1080psf/30 1920x1080 33.750 60.000
D-1080p
1920x1080 27.000 24.000
1920x1080 28.125 25.000
1920x1080 33.750 30.000
Dual SDI Board “POA-AMD17SDID”
Dual Link SDI Board “POA-AMDSDIDL”
ON-SCREEN
DISPLAy
RESOLUTION H-Freq.(kHz) V-Freq.(Hz)
480i 720x480 15.734 60.000
575i 720x576 15.625 50.000
480p 720x480 31.470 59.880
575p 720x575 31.250 50.000
1035i 1920x1035 33.750 60.000
1080i
1920x1080 33.750 60.000
1920x1080 28.125 50.000
720p
1280x720 37.500 50.000
1280x720 45.000 60.000
ON-SCREEN
DISPLAy
RESOLUTION H-Freq.(kHz) V-Freq.(Hz)
1080psf/24 1920x1080 27.000 48.000
1080psf/25 1920x1080 28.125 50.000
1080psf/30 1920x1080 33.750 60.000
1080p
1920x1080 27.000 24.000
1920x1080 28.125 25.000
1920x1080 33.750 30.000
1920x1080 56.250 50.000
1920x1080 67.500 60.000
5 BNC, S Board “POA-AMD5VD”
Appendix
ON-SCREEN
DISPLAy
RESOLUTION H-Freq.(kHz) V-Freq.(Hz)
D-480i 720x480 15.734 60.000
D-575i 720x576 15.625 50.000
D-1035i 1920x1035 i 33.750 60.000
D-1080i
1920x1080 i 33.750 60.000
1920x1080 i 28.125 50.000
D-720p
1280x720 37.500 50.000
1280x720 45.000 60.000
D-1080psf/24 1920x1080 27.000 48.000
D-1080psf/25 1920x1080 28.125 50.000
D-1080psf/30 1920x1080 33.750 60.000
ON-SCREEN
DISPLAy
RESOLUTION H-Freq.(kHz) V-Freq.(Hz)
D-1080p
1920x1080 27.000 24.000
19820x100 28.125 25.000
1920x1080 33.750 30.000
1920x1080 56.250 50.000
1920x1080 67.500 60.000
D-1080psf/24(2K) 2048x1080 27.000 48.000
D-1080psf/25(2K) 2048x1080 28.125 50.000
D-1080psf/30(2K) 2048x1080 33.750 60.000
D-1080p/24(2K) 2048x1080 27.000 24.000
