Trademarks
Each name of corporations or products in this book is either a registered trademark or a trademark of its respective corporation.
Table of Contents
Features and Design. . . . . . . . . . . . . . . .
Table of Contents . . . . . . . . . . . . . . . . . .
To The Owner . . . . . . . . . . . . . . . . . . . . . 4
Safety Instructions . . . . . . . . . . . . . . . . . 5
Air Circulation 6
Installing the Projector in Proper Directions 7
Moving the Projector 8
Compliance . . . . . . . . . . . . . . . . . . . . . . . 9
Part Names and Functions. . . . . . . . . . 10
Front 10
Back 10
Bottom 10
Terminals and Connectors 11
Side Control and Indicators 12
Side Control 12
Indicators 13
LAMP 1/2/3/4 REPLACE indicators 13
Remote Control 14
Remote Control Battery Installation 15
Remote Control Receivers and Operating Range 15
Wired Remote Control 15
Remote Control Codes 16
Installation . . . . . . . . . . . . . . . . . . . . . . 17
Lens Installation 17
Positioning Projector 17
Picture Level and Pitch Adjustment 17
Lens Shift Adjustment 18
Terminals of Projector 19
Connecting to Computer 20
Connecting to Video Equipment 21
Attaching the Cable Tie 22
Connecting the AC Power Cord 23
Basic Operation . . . . . . . . . . . . . . . . . . 4
Turning On the Projector 24
Turning Off the Projector 25
How to Operate the On-Screen Menu 26
Main Menu 27
Operating with Projector Control 28
Operating with Remote Control 29
Keystone Correction 32
Input Selection . . . . . . . . . . . . . . . . . . .
Direct Operation 33
Computer Input Source Selection 34
Video Input Source Selection 35
Computer Input . . . . . . . . . . . . . . . . . . 6
Computer System Selection 36
Auto PC Adjustment 37
Manual PC Adjustment 38
Image Selection 40
Image Adjustment 41
Screen Size Adjustment 44
Video Input . . . . . . . . . . . . . . . . . . . . . . 47
Video System Selection 47
Image Selection 48
Image Adjustment 49
Screen Size Adjustment 52
Settings . . . . . . . . . . . . . . . . . . . . . . . . . 54
Settings 54
How To Overlap the Projection Images 70
How to Overlap the Projection Images on a Screen 70
Maintenance and Care . . . . . . . . . . . . . 7
Maintaining the AMC unit 72
Replacing the Filters 73
Resetting the Filter Counter 74
Lamp Management 75
Lamp Replacement 76
Cleaning the Projection Lens 78
Cleaning the Projector Cabinet 78
Warning Indicators 79
Appendix . . . . . . . . . . . . . . . . . . . . . . . . 80
Troubleshooting 80
Menu Tree 83
Indicators and Projector Condition 86
Compatible Computer Specifications 89
Supported Signal Format for Optional Board 91
Technical Specifications 92
Optional Parts 93
PJ Link Notice 93
Configurations of Terminals 94
PIN Code Number Memo 95
Dimensions 96
List of Picture in Picture 97
Serial Control Interface 98
