7
Maintenance and Care
AMC unit
Maintaining the AMC unit
AMC unit
Filter cleaning
unit cover
Dust collects here.
RECOMMENDATION
We recommend avoiding dusty/smoky environments when
operating the projector. Usage in these environments may
cause a poor image quality.
When using the projector under dusty or smoky conditions,
dust may accumulate on a lens, liquid crystal panels, or optical
elements inside the projector. Such condition may degrade the
quality of the projected image.
When the symptoms above are noticed, contact your authorized
dealer or service center for proper cleaning.
Mesh filter
3
4
5
5
Overturn the AMC unit and loosen the 2 screws that
secure the filter cleaning unit.
Loosen the 2 screws that secure the AMC unit and
pull it out.
After opening the filter cleaning unit cover, take out
the dust bin from the filter cleaning unit, empty the
dust bin by discarding the dust into a trash bin or
carefully sucking up the dust with a vacuum cleaner,
clean the brush, place back the dust bin, and then
close the cover.
Remove the dust on the projector and air vents.
Press the ON/STAND-BY button on the side control
or the STAND-BY button on the remote control, flip
the Main On/Off Switch off, and then unplug the AC
power cord from the AC outlet.
1
2
3
4
Close the dust tray
slowly and dispose
the dust.
Screws
Screws
Dust tray
Filter cleaning unit
When you suck
up the dust with
a vacuum cleaner,
use a crevice tool.
Dust bin
6
7
Place the AMC unit back into the projector and fix it
with the 2 screws.
Plug the power cord and power on the projector.
✔ Note:
• Do not reset the filter counter if the filters were not replaced.
Brush
