Ready, Test, Scan
1. Ready
Make sure connections are secure.
2. Test
Aim the scanner away from you and press the trigger. When you press
the trigger, the scanning beam is energized for approximately 3.0
seconds (default).
3. Scan
Make sure the symbol you want to scan is within the scanning range. See
the LS 3603 Decode Zone diagram on
.
Aim and press the trigger.
The scan beam and red SCAN LED will light for about 3.0 seconds, or until a
successful decode.
The scanner has read the symbol when:
•
You hear a short, high tone beep (if the beeper is enabled).
•
The green DECODE LED lights.
The DECODE LED stays lit until the next trigger pull, unless Low Power Mode
is selected. In this case, the DECODE LED is extinguished following the decode
beep.
