1-5
User’s Guide
Wand Emulation
For external power operation:
• Plug the 9-pin connector at the end of the scanner's coil cord into one
end of the battery box.
• Use the appropriate output cable from the battery box to connect the
LS 3603 to the host device.
• Connect one end of this cable to the battery box and the other to the
appropriate port on the host device.
• Plug the power supply connector into the receptacle on the side of the
battery box. Connect the power supply plug into an AC outlet.
For direct host power operation:
Plug the scanner directly into the scanner input port of the host device.
For battery operation:
• Insert a 9-volt battery into the battery box. See the Battery Box
Operation section on page 1-10 .
• Plug the scanner's 9-pin connector at the end of the coil cord into one end
of the battery box.
• An output cable from the battery box connects the LS 3603 to the host
device. Connect one end of this cable to the battery box and the other to
the appropriate port on the host device.
