Operator’s Manual
LBA-PC
252
4 = 16x
Key Type Value
Description
FrameNumber I frame
number
-1 = gain frame
0 = reference frame
1 to n. ‘n’ is the size of the frame buffer.
default = current frame
Date
4
D
MM/DD/YY
Time
4
T
HH:MM:SS.DD
CameraInput
4
L
0 = camera 1
1 = camera 2
2 = camera 3
3 = camera 4
PixelBits
4
I
number bits in raw pixel
PixelHScale
4
F
horizontal pixel scale
PixelVScale
4
F
vertical pixel scale
PixelUnits
4
L
0 = none
1 =
µm
2 = mm
3 = cm
4 = m
5 = in
6 = mils
7 = mrad
Gamma
4
F
gamma correction performed on frame
Lens
4
B
PixelBitsFraction
4
I
number of bits in fraction
CaptureLocation
4
I,I
X,Y upper left corner of capture area (see
also PAN)
CaptureSize
4
I,I
frame width and height
CaptureResolution
4
L
-1 = Full 1x
0 = 1x
1 = 2x
2 = 4x
3 = 8x
