Operator’s Manual LBA-PC 230
YreferenceDiameter F Y reference diameter
Key Type Value Description
9 = pw
10 = fl
Quant B Quantitative results enable.
BeamWidthMethod L Beam width method.
0 = 4 sigma
1 = knife edge 90/10
2 = knife edge
3 = energy (uses ClipHigh)
4 = peak
ClipLow F 1 to 99, < ClipHigh
ClipHigh F 1 to 99, > ClipLow
Multiplier F Knife edge multiplier
1 to 10
Ellip B Elliptical results enable.
Gauss B Gauss fit enable.
GaussMethod L Gauss fit method.
0 = whole
1 = x/y or major/minor
Tophat B Tophat enable.
TophatMethod L Tophat method.
0 = data
1 = area
2 = line
Divergence B Divergence enable.
Divergence Method L Divergence method.
0 = focal length
1 = far field
FocalLength F Lens focal length
0 to 10000
Separation F Far field separation
0 to 10000
XreferenceDiameter F X reference diameter
0 to 1.0e12
