Key Type Value Description
Operator’s Manual LBA-PC
Doc. No. 10654-001, Rev 4.10
229
8 = nw
0 to NumZooms-1.
NumZooms 4 I Maximum zoom index value
CaptureLocation 4 I,I X,Y upper left corner of capture area (see
PAN)
CaptureSize 4 I,I Width and height of frame
These values are set via ZoomIndex
CaptureResolution 4 L Capture sample resolution.
-1 = Full 1x
0 = 1x
1 = 2x
2 = 4x
3 = 8x
4 = 16x
5 = 32x
This value is set via ZoomIndex.
A.5.2.4 COM - set computations configuration
:COM 1
:COM? 2
Key Type Value Description
EnergyOfBeam F Beam energy. Will calibrate the currently
displayed frame to this value.
EnergyOfFrame4 F Raw frame total at time EnergyOfBeam is
entered.
EnergyUnits L Calibrated energy units.
0 = j
1 = mj
2 = uj
3 = nj
u = pj
5 = w
6 = mw
7 = uw
