Operator’s Manual LBA-PC 232
LowerThreshold F Lower color energy display threshold.
If energy is uncalibrated (COM,
Key Type Value Description
4 = window lower left
ManualOrigin I X,Y detector location of manual origin.
Range depends on camera.
BeamColors L Beam display color.
0 = bands
1 = continuous
2 = gray scale
3 = user specified palette
4 = green
5 = yellow
PaletteFileName Name of the color palette file.
Maximum 256 characters.
default = drive, path, name of lat palette file
loaded.
ScaleType L Beam display scale.
0 = x1
1 = x2
2 = x4
3 = x8
4 = x16
5 = auto
BeamDisplay L What beams to display.
0 = current
1 = current & reference
2 = current & current - reference
3 = current & current + reference
4 = reference
5 = current - reference
6 = current + reference
ReferenceSource L Reference source.
0 = frame
1 = gauss
2 = auto gauss
