Key Type Value Description
Operator’s Manual LBA-PC
Doc. No. 10654-001, Rev 4.10
233
EnergyOfBeam=0) then the range is 0 to
255.
If
energy is calibrated then the range
depends on the energy calibration.
UpperThreshold F Upper color energy display threshold.
If energy is uncalibrated (COM,
EnergyOfBeam=0) then the range is 0 to
255.
If
energy is calibrated then the range
depends on the energy calibration.
ColorBar B Color bar display enable.
CursorAxis L Cursor axis orientation.
0 = x/y
1 = major/minor
Crosshair L Crosshair display enable.
0 = off
1 = manual
2 = centroid
3 = peak
4 = origin
Grid B 2D grid enable.
CrossHatch B 3D crosshatch enable.
Contour B 3D contour enable.
WireFrame B 3D wire frame enable.
Rotate I 3D display rotation.
0 to 359.
Tilt I 3D display tilt.
0 to 90
Slice L 3D wire density display.
0 = frame size
1 = ½ frame size
2 = ¼ frame size
3 = etc.
Minimum display is 16 X 15.
