-51-
Model M1113 (Mfg. Since 2/08)
PA
RT
S
Table.&.Guides.Parts.List
REF PART # DESCRIPTION REF PART # DESCRIPTION
101 XPB51 HEX BOLT 1/4-20 X 3/8 136 XPS01 PHLP HD SCR 10-24 X 1/2
102 XPLW02 LOCK WASHER 1/4 137 XPCAP06 CAP SCREW 1/4-20 X 1
103 XPW06 FLAT WASHER 1/4 138 XM1113138 REAR RAIL
104 XM1113104 GUIDE BAR COVER 139 XM1113139 TABLE PIN
105 XPTS001 THUMB SCREW 1/4-20 X 1/2 140 XM1113140 GAUGE
106 XM1113106 FENCE SCALE 140-1 XM1113140-1 MITER GAUGE HANDLE
107 XM1113107 GUIDE BAR 140-2 XM1113140-2 MITER GAUGE BODY
108 XM1113108 GUIDE BAR BRACKET 140-4 XM1113140-4 MITER GAUGE POINTER
109 XPW07 FLAT WASHER 5/16 140-5 XM1113140-5 MITER GAUGE BAR
110 XPLW01 LOCK WASHER 5/16 141 XM1113141 TABLE INSERT
111 XPB32 HEX BOLT 5/16-18 X 5/8 142 XM1113142 TABLE 19MM T-SLOT
112 XM1113112 HANDWHEEL SHAFT 143 XM1113143 GUIDE BAR SCALE
113 XM1113113 HANDWHEEL 144 XM1113144 POINTER PLATE
114 XPSS11 SET SCREW 1/4-20 X 1/4 146 XPB35 HEX BOLT 3/8-16 X 2-1/2
115 XPR47M EXT RETAINING RING 13MM 147 XM1113147 CLAMP SHOE
116 XM1113116 BALL 148 XM1113148 TRUNNION
117 XM1113117 COMPRESSION SPRING 149 XPB07 HEX BOLT 5/16-18 X 3/4
119 XM1113119 GUIDE BAR KNOB 5/16-18 X 2 150 XPB58 HEX BOLT 3/8-16 X 2
120 XM1113120 GEAR 151 XPW02 FLAT WASHER 3/8
121 XM1113121 EXTENSION TABLE 152 XM1113152 TABLE BRACKET
122 XPW07 FLAT WASHER 5/16 153 XM1113153 TABLE TRUNNION KNOB 3/8-16
123 XPB06 HEX BOLT 5/16-18 X 2 154 XPS18 PHLP HD SCR 10-24 X 1/4
124 XM1113124 BLADE COVER 155 XM1113155 TABLE TILT POINTER
125 XM1113125 LOCK LEVER 1/4-20 X 3/4 156 XM1113156 TABLE TILT SCALE
126 XPCAP05 CAP SCREW 1/4-20 X 3/4 157 XM1113157 LOWER SUPPORT BRACKET
127 XM1113127 GUIDE POST BRACKET 158 XM1113158 BLADE GUIDE HOLDER BOTTOM
128 XM1113128 SUPPORT BEARING SHAFT 159 XPB05 HEX BOLT 1/4-20 X 3/4
129 P6200ZZ BALL BEARING 6200ZZ 160 XM1113160 RAIL KNOB 5/16-18 X 5/8
130 XPR01M EXT RETAINING RING 10MM 161 XPSN01 SQUARE NUT 3/8-16
131 XM1113131 BLADE GUIDE BLOCK 162 XM1113162 FRONT RAIL
132 XM1113132 BLADE GUIDE HOLDER TOP 164 XPN02 HEX NUT 5/16-18
133 XPCAP06 CAP SCREW 1/4-20 X 1 165 XPCAP06 CAP SCREW 1/4-20 X 1
134 XM1113134 GUIDE POST 166 XM1113166 L-BRACKET
135 XM1113135 GUIDE HEIGHT POINTER 167 XM1113167 HANDWHEEL HANDLE
