-49-
Model M1113 (Mfg. Since 2/08)
PA
RT
S
Bandsaw.Body.Parts.List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1V1 XM1113001 BODY V1.05.07 42 XPN08 HEX NUT 3/8-16
1V2 XM1113001V2 BODY V2.02.08 43 XM1113043 HEX BOLT 3/8-16 X 4
2 XM1113002 BLADE TENSION HANDLE 44 XM1113044 COVER
3 XM1113003 TENSION HANDLE WASHER 45 XPN03 HEX NUT 3/4-16
4 XM1113004 UPPER WHEEL BRACKET 46 XPB11 HEX BOLT 5/16-18 X 1-1/2
5 XPB45M HEX BOLT M8-1.25 X 100 46-1 XPN02 HEX NUT 5/16-18
6V1 XM1113006 UPPER WHEEL SHAFT 15MM V1.05.07 46-2 XPW07 FLAT WASHER 5/16
6V2 XM1113006V2 UPPER WHEEL SHAFT 17MM V2.02.08 47 XM1113047 ADJUSTING SCREW
7V1 XP6202ZZ BALL BEARING 6202ZZ 48V1 XM1113048 BEARING HOUSING V1.05.07
7V2 XP6203ZZ BALL BEARING 6203ZZ 48V2 XM1113048V2 BEARING HOUSING V2.02.08
8V1 XM1113008 UPPER WHEEL ALUMINUM V1.05.07 49 XPN04 HEX NUT 5/8-11
8V2 XM1113008V2 UPPER WHEEL CAST IRON V2.02.08 50 XPVA41 V-BELT A-41 4L410
9 XM1113009 TIRE 51 XPSS03 SET SCREW 1/4-20 X 3/8
10V1 XPR21M INT RETAINING RING 35MM 52V1 XM1113052 WHEEL PULLEY V1.05.07
10V2 XPR23M INT RETAINING RING 40MM 52V2 XM1113052V2 WHEEL PULLEY 25MM V2.02.08
11 XPLN08 LOCK NUT 1/2-20 53 XM1113053 IDLER PULLEY
12 XM1113012 BLADE 133" LONG 54 XM1113054 MOTOR PULLEY
13 XM1113013 WHEEL GUARD HINGE PIN 55 XPVA30 V-BELT A-30 4L300
14 XM1113014 UPPER WHEEL GUARD 56 XPR05M EXT RETAINING RING 15MM
15 XM1113015 LOWER GUARD 57 XM1113057 IDLER PULLEY SHAFT
16 XPCAP05 CAP SCREW 1/4-20 X 3/4 58 XPW14 FLAT WASHER 5/8
17 XPN05 HEX NUT 1/4-20 59 XM1113059 MOTOR 1.5HP 220V 3-PH
18 XPN42 HEX NUT 3/4-10 (LH) 59-1 XM1113059-1 JUNCTION BOX REAR COVER
19V1 XM1113019 LOWER WHEEL ALUMINUM V1.05.07 59-2 XM1113059-2 JUNCTION BOX FRONT COVER
19V2 XM1113019V2 LOWER WHEEL CAST IRON V2.02.08 59-3 XPS18 PHLP HD SCR 10-24 X 1/4
20V1 XM1113020 SPACER 59-4 XM1113059-4 TERMINAL BLOCK C-CIRCUIT
21V1 XM1113021 LOWER WHEEL SHAFT V1.05.07 60 XPW02 FLAT WASHER 3/8
21V2 XM1113021V2 LOWER WHEEL SHAFT 25MM V2.02.08 61 XM1113061 SPECIAL SCREW 3/8-16 X 1-1/4
22 XPN08 HEX NUT 3/8-16 62 XPB35 HEX BOLT 3/8-16 X 2-1/2
23V1 XP6204 BALL BEARING 6204ZZ 63 XM1113063 SWITCH COVER
23AV2 XP6205ZZ BALL BEARING 6205ZZ 64 XPS17M PHLP HD SCR M4-.7 X 6
23BV2 XP6005ZZ BALL BEARING 6005ZZ 65 XPS109M PHLP HD SCR M3-.5 X 18
24 XPK23M KEY 5 X 5 X 25 66 XPS01M PHLP HD SCR M4-.7 X 18
25 XPN03M HEX NUT M8-1.25 67 XPS04 PHLP HD SCR 1/4-20 X 1/2
26V1 XPLW07 LOCK WASHER 1/2 68 XPS08 PHLP HD SCR 10-24 X 3/4
26V2 XPLW06 LOCK WASHER 5/8 69 XM1113069 CONTROLLER COVER PLATE
27 XM1113027 CORD 4-WIRE 16AWG 70 XPN07 HEX NUT 10-24
30V1 XPLN08 LOCK NUT 1/2-20 71 XM1113071 MOTOR INVERTER SWITCH
30V2 XPLN15 LOCK NUT 5/8-18 72 XM1113072 SPEED DIAL
31 XM1113031 PLATE NUT 73 XM1113073 SWITCH W/LARGE STOP
32 XM1113032 BLADE TENSION POINTER 74 XM1113074 INVERTER RHYMEBUS RMG-5 1HP
33 XM1113033 COMPRESSION SPRING 75 XPB03 HEX BOLT 5/16-18 X 1
34 XM1113034 STRAIN RELIEF 76 XPN02 HEX NUT 5/16-18
35 XPN02 HEX NUT 5/16-18 77 XM1113077 BRUSH BASE
36 XM1113036 BLADE TRACKING KNOB 78 XPS10 PHLP HD SCR 10-24 X 1-1/2
37 XM1113037 POWER CORD 3-WIRE 16AWG 79 XM1113079 BRUSH
38 XM1113038 DOOR COVER KNOB 80 XPB19 HEX BOLT 1/4-20 X 1/2
39 XPCAP05 CAP SCREW 1/4-20 X 3/4 81 XPLW02 LOCK WASHER 1/4
40 XM1113040 CORD 3-WIRE 16AWG 82 XPW06 FLAT WASHER 1/4
41 XM1113041 PIN 6MM
V1 = Models Manufactured Before 02/08 V2 = Models Manufactured Since 02/08
