99-00582-20 REV A0 Setting Up the 4000i 11
1. Connect the included bundle of laptop connection cables to the corresponding receptacles on
the 4000i’s rear panel.
2. Connect the other end of the laptop connection cables to the appropriate receptacles on the
guest laptop.
NOTE: Most modern laptops have USB 2.0 receptacles instead of a DB9 serial receptacle.
The 4000i includes a DB9 serial to USB converter cable in the bundle of laptop cables.
To connect a guest laptop
VCR/DVD Audio OUT
Computer 2 Inputs
Output
Network
Audio IN
Audio OUT
Printer
Computer 2 Serial
R L
Laptop serial input
Laptop sound input
Laptop video input
