6 Setting Up the 4000i 99-00582-20 REV A0
5. Open the cabinet’s front doors. Unbuckle and remove the strap that secures the small mirror
located in the middle of the speaker panel, below the projector platform.
Installing and Connecting a Computer
1. While facing the front of the cabinet, slide the computer into place at the right-hand side of the
cabinet, above the computer straps. Use the straps to secure the computer.
NOTE: The computer straps enable you to roll the cabinet from room to room without having
to remove the computer. However, these straps won’t secure the computer during cabinet
shipment. If you need to transport the 4000i, remove the computer before you ship it.
2. Locate the tie-wrapped bundle of cables dangling inside the cabinet. There are also power,
keyboard and mouse cables located nearby.
To install and connect a computer
Remove this strap.
Video
Audio
Serial
Printer
Network
Mouse
Keyboard
